E14 Lamp Cap Gauge With Candle Shaped Shaft For Candle Lamps 7006-30A-1

Brand Name:	Kingpo	Material:	Hardness Steel
Standard:	IEC60061-3	HRC:	C58 To C60
Highlight:	Go No Go Gauge, Go And Not Go Gauge

Brand Name:

Kingpo

Material:

Hardness Steel

Standard:

IEC60061-3

HRC:

C58 To C60

Highlight:

Go No Go Gauge,

Go And Not Go Gauge

Send Inquiry Chat Now

Product Details
Inquiry

Product Description

Plug gauge for lampholder E14 with candle shaped shaft for candle lamps for testing contact making | 7006-30A-1

This gauge is used for testing contact making in lampholder with candle shaped shafts designed especially to take candle lamps only.
When the switch is in position 1 and the gauge is screwed home in the holder, the indicator lamps shall light.

E14 Lamp Cap Gauge With Candle Shaped Shaft For Candle Lamps 7006-30A-1 0

RELATED GAUGES:

“go” Gauges For Screw Threads of Lampholders E14, 7006-25-7
“not go” gauges for screw threads of lampholders E14, 7006-26-4
Plug Gauge For E14 Lampholder For Testing Contact Making, 7006-30-2
Gauge For Testing Contact-Making of Lamps In Lampholders E14, 7006-31-4
Plug Gauge for Lampholders E14 with candle shaped shaft for candle lamps for testing contact making, 7006-30A-1
