AD1000-8 Electroacoustic Tester With Dual-Channel Analog Output, 8-Channel Analog Input, SPDIF Digital Input And Output Ports

AD1000-8 is an extended version based on AD1000-4. It has stable performance and other advantages, is dedicated to the production line multi-channel product testing. With dual-channel analog output, 8-channel analog input, SPDIF digital input and output ports, AD1000-8 meets most of the production line test needs. With integrated audio test system into AD1000-8, a wide range of low-power electro-a ...

Send Inquiry Chat Now

Product Details
Inquiry

Key Features

◆ Analog 2- channel output, 8- channel input
◆ Standard configuration supports SPDIF digital interface
◆ Support basic and commonly used electro-acoustic parameter test functions, adapt to 95% production line test

◆ Code-free, complete a comprehensive test within 3 seconds
◆ Support LabVIEW , VB.NET , C#.NET , Python and other languages for secondary development
◆ Automatically generate test reports in various formats

Performance

Analog Output
Number Of Channels	2 Channels, Balanced / Unbalanced
Signal Type	Sine Wave, Dual-Frequency Sine Wave, Out-Of-Phase Sine Wave , Square Wave Signal, Frequency Sweep Signal, Noise Signal, WAVE File
Frequency Range	2Hz ~ 20kHz
Residual THD+N	＜ -103dBu @ 1kHz 1.0V

Analog Input
Number Of Channels	8 Channels, Balanced/Unbalanced
Residual Input Noise	<-108dBu @ 1kHz 1.0V
Maximum FFT Length	1248k
Frequency Measurement Range	10Hz ~ 22kHz

Digital Output
Number Of Channels	Single Channel (Two Signals), Unbalanced
Sampling Rate	44.1kHz ~ 192kHz
Sample Rate Accuracy	±0.001%
Signal Type	Sine Wave, Dual-Frequency Sine Wave, Out-Of-Phase Sine Wave, Frequency Sweep Signal, Square Wave Signal, Noise Signal, WAVE File
Signal Frequency Range	2Hz ~ 95kHz

Digital Input
Number Of Channels	Single Channel (Two Signals), Unbalanced
Voltage Measurement Range	-110dBFS ~ 0dBFS
Voltage Measurement Accuracy	< 0.001dB
Output Standard	Standard SPDIF-EAIJ(IEC60958)
